0 (0) | Rated Voltage and Power | |
| Rated Voltage and Power | 110–240 VAC; 50/60 Hz; 1.5A |
| External power adapterDC output | 12VDC |
| Video | |
| Video Standard | PAL or NTSC |
| Compression | H.264 |
| Outputs | HDMI/VGA |
| Audio | |
| Inputs | N/A |
| Output | N/A |
| Monitors | |
| Monitors | Live, playback, menus |
| Live Resolution | SVGA: 800x600, 1024x768, 1280x1024, 1360x768, 1440x900, 1920x1080PAL: 704x576, NTSC: 704x480 |
| Display Modes | |
| Screen | Full, full sequence, quad, multi-screen (live and playback), event call-up (live) |
| Frame rate PAL/NTSC | 25/30 IPS per channel (real time) |
| Multi-screen mode 8 channels | 1, 2x2, 3x3 |
| Digital Zoom | Yes |
| Display languages | Arabic, Portuguese, English, French, Deutscher, Russian, HUNGARIAN, ITALIAN, Japanese, POLAND, Roman, Chinese, Spanish, Turkish, SUOMI |
| Alarm Handling | |
| Inputs | Golbong IP camera |
| Outputs | N/A |
| Events | Motion detect, Video Blind, Video Loss, IPC Alarm |
| Remote notification | Via Control Center software, email, Push message |
| Malfunction relay | Disk space low, IP conflict, Disk failures |
| Connections | |
| Ethernet | 10/100 Base-T, auto-sensing, half/fullduplex, RJ45 |
| USB | Two USB 2.0 ports |
| Network | |
| Protocols | HTTP, TCP/IP, ARP, RTSP, RTP, UDP, SMTP, FTP, DHCP, DNS, DDNS, PPPOE, UPNP, NTP |
| IP cameras | 3045-36: 4 IP at 2mp3045-75: 8 IP at 2mp |
| Supported IPdevices | Golbong IP Cameras, Onvif 2.0 compliance IPC |
| Storage | |
| Internal HDD | 1 unit |
| Redundancy | N/A |
| Exporting | |
| USB | Flash memory |
| Network | Golbong Software |
| Security | |
| Password protection | Multi-level |
| Recording | |
| Overwrite modes | Continuous, overwrite |
| Playback | |
| Decoding Capacity | 3045-36: @ 30 fps (1-CH) 3045-75: @ 60 fps (2-CH) |
| Playback function | Fast forward/reverse, frame forward /reverse,freeze |
| Digital Zoom | yes |
| Search mode | Date/time, Event (motion, input) |
| Mechanical | |
| Dimensions (W x D x H)(excluding cabling) | 105.4(L) x 63.5(H) x 30.5(W)mm |
| Weight | TBA |
| Environmental | |
| Operating temperature | +5 °C to +45 °C (+41 °F to +113 °F) |
| Storage temperature | -25 °C to +70 °C (-13 °F to +158 °F) |
| Relative humidity | Operating: <93 % non-condensing Storage: <95 % non-condensing |
| Ordering Information | |
| 8CH PoE NVR | 3045-36 |
| 4CH PoE NVR | 3045-75 |
