0 (0) | Rated Voltage and Power | |
| Rated Voltage and Power | 110–240 VAC; 50/60 Hz; 1.5A |
| External power adapter | DC12V/2A |
| Video | |
| Video Standard | PAL or NTSC |
| Compression | H.264 |
| Max. IP Connecting | 8CH 1080P/ 16CH 720P/ 32CH D1 |
| Outputs | HDMI/VGA/BNC |
| Audio | |
| Inputs | N/A |
| Output | 4 line out, ono RCA, 1 Vpp, 10 kohm |
| Compression | G.711 |
| Sampling rate | 8 kHz per channel |
| Monitors | |
| HDMI/VGA/BNC | Live, menus |
| Live Resolution | SVGA: 800x600, 1024x768, 1280x1024, 1360x768, 1440x900, 1920x1080 PAL: 704x576, NTSC: 704x480 |
| Connections | |
| Ethernet | 10/100 Base-T, auto-sensing, half/full duplex, RJ45 |
| USB | 4 USB 2.0 |
| HDMI | 4 HDMI |
| VGA | 4 VGA |
| BNC | 4 BNC |
| Network | |
| Supported devices | Golbong IP Cameras, NVR, DVR, Onvif IP camera |
| Mechanical | |
| Dimensions (W x D x H) (excluding cabling) | 350(L) x 295(H) x 45(W)mm |
| Weight | TBA |
| Environmental | |
| Operating temperature | +5 °C to +45 °C (+41 °F to +113 °F) |
| Storage temperature | -25 °C to +70 °C (-13 °F to +158 °F) |
| Relative humidity | Operating: <93 % non-condensing Storage: <95 % non-condensing |
| Ordering Information | |
| Digital Video Decoder | 5808 |
